Pramet 7038024 Turning Insert Pramet, ANSI Code: CNMG 322-NMR:T9325, CNMG Insert, Material Grade: K, M, P, S, 322 Insert, Diamond Shape, 9 Seat, Negative Rake, For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys, Carbide
Part #PRA7038024
MFG #7038024
UNSPC #23242107
Country Of Origin : CZ
Pramet Turning Insert Pramet, CNMG Insert, 322 Insert, Diamond, 3 mm Maximum Depth of Cut, 9.525 mm Inscribed Circle, 3.18 mm Thickness, 9.7 mm Length, 9 Seat, Negative Rake, NMR Chipbreaker, 0.8 mm Corner Radius, 3.81 mm Hole Dia, Manufacturer's Grade: T9325, ANSI Code: CNMG 322-NMR:T9325, ISO Code: CNMG 090308E-NMR:T9325, 80 deg Included Angle, 0 deg Relief Angle, Carbide, MT-CVD Coated, Material Grade: K, M, P, S, For Use On: Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys
- Medium and High Feeds
- T9325 grade functionally gradient substrate
- Relatively low content of cobalt binder phase
- Thick MT-CVD coating
- Highly versatile material with very good operational reliability
- Special surface finish for coating
- Medium and higher cutting speed
- Continuous and interrupted cut
- Unfavorable cutting conditions, continuous and/or interrupted cuts
ANSI Code CNMG 322-NMR:T9325 Chipbreaker NMR Corner Radius 0.8 mm Finish MT-CVD Coated For Use On Cast Iron, Stainless Steel, Steel and Titanium/Super Alloys Hole Diameter 3.81 mm Included Angle 80 deg Inscribed Circle 9.525 mm Insert Size 322 Insert Style CNMG Length 9.7 mm Material Carbide Material Grade K, M, P, S Rake Negative Relief Angle 0 deg Seat Size 9 Shape Diamond Thickness 3.18 mm
